Effect of electrical conductivity and Nutrient Concentrations of Soilless Media Monitored with the Internet of Things (IoT) Sensor Nodes on Growth of Rock Melon

Authors

  • Salisu Monsuru Adekunle Department of Agricultural Science, Faculty of Technical and Vocational, Sultan Idris Education University 35900 Tanjung Malim, Perak, MALAYSIA
  • Ridzwan Che Rus Department of Agricultural Science, Faculty of Technical and Vocational, Sultan Idris Education University 35900 Tanjung Malim, Perak, MALAYSIA
  • Norhanizan Usaizan Department of Agricultural Science, Faculty of Technical and Vocational, Sultan Idris Education University 35900 Tanjung Malim, Perak, MALAYSIA
  • Irdayanti Mat Nashir Department of Engineering Technology, Faculty of Technical and Vocational, Sultan Idris Education University 35900 Tanjung Malim, Perak, MALAYSIA
  • Hussain Luqman Department of Agriculture, College of Vocational and Entrepreneur Education (COVED), Lagos State University of Education, Epe Campus, Lagos NIGERIA
  • Peter Wusu Olugbemi Department of Agriculture, College of Vocational and Entrepreneur Education (COVED), Lagos State University of Education, Epe Campus, Lagos NIGERIA
  • Yusuff Oladosu Institute of Tropical Agriculture and Food Security, Universiti Putra Malaysia, Serdang 43400, MALAYSIA

DOI:

https://doi.org/10.53797/agrotech.v2i1.3.2023

Keywords:

EC levels, Fruit quality, IoT Sensor nodes, Rockmelon, Soilless media

Abstract

The challenges of managing traditional agricultural planting have prompted the implementation of the internet of things (IoT) to enable real-time detection and intelligent management of crop growth.  The IoT-based monitoring solution was purposely designed to gauge the moisture content, and electrical conductivity (EC) in newly prepared soilless media, The newly soilless media were codded M1 which contains proportions of CD, burnt rice husk, and perlite at different percentages. The M2 contains CD, burnt rice husk, and perlite, M3 contains Coconut coir dust, vermiculite, and perlite, M4 had CD, perlite while M5 designated as control evaluation had 100% CD. The experiment was conducted in a greenhouse. The nutrient concentrations and EC levels were determined with a customized portable internet of things (IoT) system. Relevant real-time agronomic data were collected. The highest EC level was observed in M2 and M3 with 1.4 dS/m and 1.3 dS/m, respectively. Soilless medium M2 and M3 noticeably showed the highest nitrogen and phosphorus concentration and were significantly different from M1, M4 and M5 while the highest potassium concentration was recorded in M2. The EC and nutrient concentration translated into the highest leaf area, plant height, highest number of leaves, and greater leaf weight. Total fresh fruit weight was significantly greater in soilless media M2 3.17 kg/plant and M3 3.34 kg/plant. The highest soluble solid content (SSC) was influenced by the M2. Consequently, the proportions of the materials in both soilless media could be considered for achieving robust growth and fruit quality of rockmelon.

Downloads

Download data is not yet available.

References

Ab Rauf, M. N. H. ., & Shahruddin, S. (2022). The Effect of Different Growing Media on Physical Morphology of Rockmelon (Cucumis Melo Linn cv. Glamour) Seedling. AgroTech- Food Science, Technology and Environment, 1(1), 17-24.

Adekunle, S.M. (2017). Influence Of Soilless Potting Mix and Root Trainers on Growth of Rubber (Hevea brasiliensis Muell. Arg) Seedlings. Ph.D. Thesis, Universiti Putra Malaysia, Selangor. pp. 45 – 48.

Barrett, G., Alexander, P., Robinson, J., & Bragg, N. (2016) Achieving environmentally sustainable growing media for soilless plant cultivation systems – a review, Scientia Horticulturae, 212, 220–234.

Bartczak, M., Pietrowska, M., & Knaflewski, M. (2007) Effect of substrate on vegetative quality of strawberry plants (Fragaria ananassa Duch.) produced by a soilless method, Folia Horticulturae, 2, 39–46.

Che Nordin, R., Abdul Mutalib, A., Ismail, Z. ., & Ab Latif, Z. (2022). Effects of Liquid Organic Fertilizers and Boron Application on Growth of Tomato (Solanum lycopersicum) in Soilless Media. AgroTech- Food Science, Technology and Environment, 1(2), 26-31.

Ebrahimi, R., Ebrahimi, F., & Ahmadizadeh, M. (2012) Effect of different substrates on herbaceous pigments and chlorophyll amount of strawberry in hydroponic cultivation system. American-Eurasian Journal of Agricultural and Environmental Sciences, 12 (2),154–158.

Ismail S.I., Noor Asha N.A., & Zulperi1, D. (2020) First Report of Fusarium incarnatum-equiseti Species Complex Causing Leaf Spot on Rockmelon (Cucumis melo) in Malaysia. Plant Disease, 105, 4. Disease Note.

Karam, D. S., Nagabovanalli, P., Rajoo, K. S., Ishak, C. F., Abdu, A., Rosli, Z., & Zulperi, D. (2021) An overview on the preparation of rice husk biochar, factors affecting its properties, and its agriculture application. Journal of the Saudi Society of Agricultural Sciences, 21(3), 149-159.

Kulkarni, M.S., Mirgal, P.G., Bodhale, P.P., & Tande, S.N. (2014) Effect of rice husk ash on properties of concrete. Journal of Civil Engineering and Environmental Technology, 1(1), 26-29.

Kingston, P.H., Scagel, C.F., Bryla, D.R., & Strik, B.C. (2020). Influence of perlite in peat-and coir-based media on vegetative growth and mineral nutrition of highbush blueberry. HortScience, 55(5), 658-663.

Leskovar, D., & Othman, Y. (2016) Low nitrogen fertigation promotes root development and transplant quality in globe artichoke. HortScience, 51, 567–572.

Miller, J.H., & Jones, N. (1995) Organic and compost-based growing media for tree seedling nurseries. World Bank technical paper, 264.

Muhammad, R.M., Masdek, N.R.N.M., Ponari, S.Z., Makup, J.A., & Dardak, R.A. (2017) Technology adoption among melon agropreneurs in Sabah and Sarawak: An analysis using Fuzzy Logic. Economic and Technology Management Review, 12, 19-27.

Noar N.A.Z.M., & Kamal, M.M. (2017) The development of smart flood monitoring system using an ultrasonic sensor with blank applications. Proc. of the 4th IEEE International Conference on Smart Instrumentation, Measurement and Applications (I.C.S.I.M.A.) 28-30 November 2017, Putrajaya, Malaysia, 1-6.

Pardossi, A., Malorgio, F., Incrocci, L., Campiotti, C.A., & Tognoni, F. (2002). A comparison between two methods to control nutrient delivery to greenhouse melons grown in recirculating nutrient solution culture. Scientia horticulturae, 92, 89-95.

Raviv, M., Wallach, R., Silber, A., & Bar-Tal A. (2002). Substrates and their analysis. In "Hydroponic production of vegetables and ornamentals" Athens, 1-86.

Rakocy, J.E., Shultz, R.C., Bailey, D.S., Pantanella, E., & Danaher, J.J. (2009) Alternative media types for seedling production of lettuce and basil. International Symposium on Growing Media and Composting, 257-264.

Rouphael, Y., & Colla, G. (2005) Growth, yield, fruit quality and nutrient uptake of hydroponically cultivated zucchini squash as affected by irrigation systems and growing seasons. Scientia horticulturae, 105(2), 177– 195.

Rouphael, Y., Cardarelli, M., Rea, E., & Colla, G. (2008). The influence of irrigation system and nutrient solution concentration on potted geranium production under various conditions of radiation and temperature. Scientia horticulturae, 118, 328-337.

Trejo-Téllez, L.I., & Gómez-Merino, F,C. (2012) Nutrient Solutions for Hydroponic Systems. In Hydroponics - A Standard Methodology for Plant Biological Researches, IntechOpen, 1-24.

Sharrar, L., Buyamin, S., & Abidin, M.S.Z. (2021). The Development of a Smart Moisture Monitoring System for Precision Agriculture. 7th International Symposium on Affective Science and Engineering, 431 – 434.

Sang, H., Jiao, X., Wang, S., Guo, W., Salahou, M. K., & Liu, K. (2018). Effects of micro-nano bubble aerated irrigation and nitrogen fertilizer level on tillering, nitrogen uptake and utilization of early rice. Plant, Soil and Environment, 64(7), 297-302.

Salisu, M.A., Sulaiman, Z., Rus, R.C., Samad, M.Y.A., Usaizan, N., & Oladosu, Y. (2020). Water use efficiency, plant growth and vegetative traits of rubber ('Hevea brasiliensis') seedlings grown using different growing media and water levels. Australian Journal of Crop Science, 14(9), 1497-1505.

Sindhu, S. S., Dua, S., Verma, M. K., & Khandelwal, A. (2010). Growth promotion of legumes by inoculation of rhizosphere bacteria. In Microbes for legume improvement. Springer, Vienna, 195-235.

Villanueva, M.J., Tenorio, M.D., Esteban, M.A., & Mendoza, M.C. (2004) Compositional changes during ripening of two cultivars of muskmelon fruits. Food Chemistry, 87, 179-185.

Veit‐Köhler, U., Krumbein, A., & Kosegarten, H. (1999) Effect of different water supply on plant growth and fruit quality of Lycopersicon esculentum. Journal of Plant Nutrition and Soil Science, 162(6), 583-588.

Wang, D., Gabriel, M., Legard, D., & Sjulin, T. (2016). Characteristics of growing media mixes and application for open-field production of strawberry (Fragaria ananassa). Scientia Horticulturae, 198:294–303.

Zulkarami, B., Ashrafuzzaman, M., & Razi, I.M. (2010) Morpho-physiological growth, yield and fruit quality of rock melon as affected by growing media and electrical conductivity. Journal of Food, Agriculture and Environment, 8(1), 249-252

Downloads

Published

2023-05-18

How to Cite

Monsuru Adekunle, S., Che Rus, R., Usaizan, N., Mat Nashir, I., Luqman, H., Olugbemi, P. W., & Oladosu, Y. (2023). Effect of electrical conductivity and Nutrient Concentrations of Soilless Media Monitored with the Internet of Things (IoT) Sensor Nodes on Growth of Rock Melon. AgroTech- Food Science, Technology and Environment, 2(1), 21-28. https://doi.org/10.53797/agrotech.v2i1.3.2023
